GEL
Stored Pressure 2ltr, 4ltr, 6ltr and 9ltr.
Lithium fire extinguishing gel works by cooling and smothering the fire. When applied, the gel forms a protective layer that absorbs heat, reducing the fire's temperature. Simultaneously, it blocks oxygen, suffocating the flames and preventing the fire from spreading. This makes it highly effective for extinguishing lithium-based battery fires.
Click image for large preview
effect
refillable
friendly
re-ignition
friendly
of spare parts are available
MODEL NO | SPF-2Li | SPF-4Li | SPF-6Li | SPF-9Li |
---|---|---|---|---|
CYLINDER MATERIAL | M.S. | M.S. | M.S. | M.S. |
CAPACITY (KG) | 2 | 4 | 6 | 9 |
FIRE RATING | 1A 34B | 2A 55B | 3A 89B | 4A 144B |
EXTINGUISHING MEDIUM | GEL | GEL | GEL | GEL |
TEMPERATURE RANGE | -30ºC to +60ºC | +05ºC to +60ºC | +05ºC to +60ºC | +05ºC to +60ºC |
DISCHARGE TIME | MORE THAN 08 S | MORE THAN 15 S | MORE THAN 16 S | MORE THAN 20 S |
DISCHARGE RANGE | MORE THAN 03 M | MORE THAN 02 M | MORE THAN 02 M | MORE THAN 02 M |
OPERATING PRESSURE | 15 BAR | 15 BAR | 15 BAR | 15 BAR |
TEST PRESSURE | 35 BAR | 35 BAR | 35 BAR | 35 BAR |
EXPELLANT | NITROGEN | NITROGEN | NITROGEN | NITROGEN |
Ensure fire safety, save life save property. Carelessness is the biggest cause of fire.
