HOSE REEL DRUM

HOSE REEL DRUM

Project

Click image for large preview

‹
›
Project
Project

ISI Marked

1 year warranty

Project

COMPACT

& Space saving

Project

VERSATILE

Mounting options

Controlled

discharge

Project

Supplied

with wall bracket

Full range

of spare parts are available

Enquire Now

SWINGING TYPE WALL MOUNTED FIRST AID HOSE REEL DRUM

Technical Specification

  • Conforming To : IS:884/1958
  • Size : Inlet:1"ThreadedInlet Connection
  • Type : Swinging 180' Wall Mounting
  • Outlet : 3/4",1",1-1/2" outlet connection for House to accommodate
  • 30/36/40Mtrs. Hose

    • Performance Test

  • Hydraulic Test : Tested at 21 Kgf/cm2
  • Range & Water Flow rate test at 7Kgf/cm2
  • (A)Discharge : 24LPM
  • (B)Range(Jet Length) : 6Mtr (Min) Halogram : Sticker Stuck On Wheel

    • HUB SIDE & WALL BRACKET M.S. SHEET OF IS : 513
    SWIVEL JOINT STEEL OF IS : 1239 PART 1
    NOZZLE IS : 8090
    HOSE REEL TUBING THERMOPLASTIC HOSE CONFIRMING TO IS : 12585 RUBBER HOSE CONFIRMING TO IS : 444
